High Efficiency Oil Mist Removal Filter Cartridge Low Resistance CNC Lathe Milling Machine Oil Smoke Filter Element
Our CNC oil mist filter cartridges adopt high-quality gradient glass fiber composite filter material with outer coarse and inner fine structural design, which perfectly solves the problem of ultra-fine oil mist diffusion in CNC machining workshops. It accurately intercepts 0.1μm tiny oil mist particles with up to 99.9% purification efficiency, thoroughly removing cutting fluid oil smoke and industrial oily exhaust gas. The unique oil storage and self-return structure realizes efficient oil-gas separation, adsorbed oil liquid flows back to the equipment automatically, realizing cutting fluid recycling and saving production cost. The filter cartridge maintains ultra-low air resistance during long-term operation, which will not affect the exhaust efficiency of the oil mist collector. Equipped with double-layer metal protective mesh, it features high strength, corrosion resistance and no fiber shedding. It is an essential consumable for long-term stable operation of CNC machine tools and industrial oil mist purification systems.
Brand:
guanlin
Spu:
CNC YWLX-2
Description
Product Standard Parameters
Parameter Item |
Technical Specification |
Filter Material |
High-density Glass Fiber / Composite Polyester Gradient Filter Material |
Outer/Inner Frame |
Galvanized Steel / Stainless Steel Protective Mesh |
Filtration Precision |
0.1μm Ultra-fine Oil Mist Particle |
Filtration Efficiency |
99.8% ~ 99.9% Oil Mist Removal Rate |
Working Temperature |
≤80℃ Long-term Continuous Operation |
Core Performance |
Gradient adsorption, high oil holding capacity, low air resistance, oil return recyclable, anti-corrosion, no fiber shedding |
Structural Feature |
Outer coarse & inner fine gradient structure, self-drainage oil return design |
Application Scenarios |
CNC lathe, milling machine, machining center, industrial oil mist collector, workshop oil smoke purification |
Process Treatment |
Integrated folding and bonding, double-layer protective mesh, end cap reinforcement, leak-proof sealing |
Customization Service |
Custom diameter, height, mesh material and filtration grade |
omprehensive Core Selling Points
Our CNC oil mist filter cartridges adopt high-quality gradient glass fiber composite filter material with outer coarse and inner fine structural design, which perfectly solves the problem of ultra-fine oil mist diffusion in CNC machining workshops. It accurately intercepts 0.1μm tiny oil mist particles with up to 99.9% purification efficiency, thoroughly removing cutting fluid oil smoke and industrial oily exhaust gas. The unique oil storage and self-return structure realizes efficient oil-gas separation, adsorbed oil liquid flows back to the equipment automatically, realizing cutting fluid recycling and saving production cost. The filter cartridge maintains ultra-low air resistance during long-term operation, which will not affect the exhaust efficiency of the oil mist collector. Equipped with double-layer metal protective mesh, it features high strength, corrosion resistance and no fiber shedding. It is an essential consumable for long-term stable operation of CNC machine tools and industrial oil mist purification systems.
Key product selling points and advantages.
1. Gradient Density Structure, Ultra-high Oil Mist Purification
EN：Adopts outer-coarse-inner-fine gradient fiber structure, which layers and intercepts large oil droplets and ultra-fine oil mist step by step. The filtration accuracy reaches 0.1μm, solving the problem of fine oil mist escaping from ordinary filters.
2. Self-oil-return Design, Realize Cutting Fluid Recycling
EN：Unique capillary adsorption and gravity oil return structure. The adsorbed oil mist condenses into liquid and flows back to the machine tool tank automatically, realizing oil liquid recycling and greatly reducing cutting fluid consumption.
3. Super High Oil Holding Capacity, Long Service Cycle
EN：High-density glass fiber material has huge oil storage space, with strong adsorption capacity for long-term continuous oil mist. It is not easy to saturate and block, effectively extending the replacement cycle and reducing maintenance frequency.
4. Ultra-low Wind Resistance, No Impact on Equipment Exhaust
EN：Uniform and breathable fiber structure ensures high filtration efficiency while maintaining low and stable air resistance. It will not cause exhaust pressure drop or poor smoke exhaust, ensuring stable operation of the oil mist collector.
5. Double-layer Protective Mesh, Deformation & Corrosion Resistant
EN：Adopts galvanized or stainless steel double-layer protective mesh, with strong overall stereoscopic strength. It resists negative pressure impact and oily gas corrosion, no fiber shedding, safe and pollution-free.
6. Perfect Compatibility & High Cost Performance
EN：Standard and customizable sizes are fully compatible with all brands of CNC oil mist collectors. It replaces expensive original filter elements with stable purification effect, greatly reducing workshop operating costs.
Oil Mist Purification Challenges and Answers | Specific Questions and Answers
Q1：A large amount of oil mist is generated during CNC machining, ordinary filters cannot clean ultra-fine oil mist, resulting in oily smoke floating in the workshop?
EN Solution：Conventional single-layer filter materials can only block large oil droplets, and 0.1μm ultra-fine oil mist directly escapes. Our gradient CNC oil mist filter element achieves step-by-step layered filtration, accurately capturing tiny oil mist particles with 99.9% purification rate, thoroughly cleaning workshop oil smoke.
Q2：Filter elements are easily saturated and clogged, causing reduced suction and poor exhaust effect of oil mist collectors?
EN Solution：Ordinary filter cartridges have single pore structure and limited oil storage capacity, which are quickly saturated and blocked. Our gradient glass fiber material has super large oil holding space and anti-blocking performance, maintaining stable suction and exhaust efficiency for a long time.
Q3：Filter elements cannot return oil after absorbing oil mist, resulting in serious waste of cutting fluid and high production cost?
EN Solution：Common filter materials lack oil return structure, absorbed oil mist accumulates and deteriorates inside the cartridge. Our self-drainage filter design condenses oil mist into liquid and flows back to the machine tool, realizing cutting fluid recycling and saving raw material cost.
Q4：Low-quality filter elements shed fibers easily, contaminating workpieces and affecting CNC machining accuracy?
EN Solution：Cheap unprotected filter materials are loose and easy to shed debris. Our filter cartridge adopts integral bonding process + double-layer metal mesh protection, with tight internal fiber structure, zero fiber shedding, effectively protecting machine tools and processing parts from pollution.
Q5：Ordinary filter elements are easy to deform and corrode in oily environment, with short service life and frequent replacement?
EN Solution：Our glass fiber composite material has excellent oil corrosion resistance and structural stability. The reinforced outer frame resists negative pressure deformation. It has a service life 2-3 times that of ordinary filter elements, reducing replacement frequency and labor cost.
Q6：Original brand oil mist filter elements are too expensive, leading to high long-term operation and procurement costs?
EN Solution：Our replacement CNC oil mist filter cartridges fully match the installation size and performance parameters of original parts. With the same purification effect and longer service life, it greatly reduces the overall operating cost of CNC workshop oil mist purification system.
